Modern cameras are jammed solid with automatic functions, but the real creative control comes when you switch to manual and take the decisi...
Modern cameras are jammed solid with automatic functions, but the real creative control comes when you switch to manual and take the decision making into your own hands. Understanding depth of field is the key to unlocking selective focusing as a powerful creative tool.
While we’ve never had it better when it comes to cameras that simplify the technicalities of photography (including black and white photography) all those special effects and digital filters, for example but if you really want to be in control of the end result… well, you have to take control. Modern digital cameras retain a full suite of manual controls and, if you’re still flying on auto pilot, you’ll be amazed what you can achieve with them.
It’s really not as difficult as it might look and, once you’re more involved with the picturemaking process, you’ll also be surprised at how much more enjoyable and rewarding your photography will become.
Depth of field is often perceived as the photographic technicality that causes the most confusion and looks the most difficult to comprehend, but once you grasp the basic principle, it’s actually not all that mysterious and certainly very useful in all areas of photography and film photography. Importantly, depth of field may be one of photography’s key technical considerations, but it also has many creative implications.
The aperture mechanism in a lens (also called the ‘diaphragm’) creates an opening which varies in size, thereby allowing progressively more or less light to pass through and reach the sensor. Along with the shutter speed, the aperture setting is how an exposure is controlled. The size of the aperture is expressed as an ‘f-stop’ which is written as the letter ‘f’ followed by a number. These numbers are determined by a simple equation; the focal length of the lens divided by the diameter of the aperture. You don’t really need to know this because f-stops are always marked on the lens or shown in the camera’s readout displays, but it will help you understand why aperture f-stops are numbered in the opposite way to what would seem logical the larger apertures have smaller f-numbers.
Typically, a modern lens has an aperture range from f2.8 its largest or widest diameter opening to f22, its smallest aperture. However, some lenses, may have a larger maximum aperture say f2.0, even f1.4 and some may have a smaller minimum aperture of f32. Zoom lenses may have a variable maximum aperture which is related to its focal or zooming range such as f3.5-5.6 but some zooms are constant aperture which means there’s no variation in an aperture setting across the zooming range.
Controlling the depth of field in this way has visual implications. A shallow depth of field is desirable if you want to throw the background out of focus so it doesn’t create any distractions or conflict with the main subject in your picture. Alternatively, longer depth of field may be required if you want details in both the foreground and background to be in sharp focus such as may be required in landscape photography where both the details in the foreground and background are important.
A very shallow depth of field allows for selective focusing so the viewer’s eye is only drawn to the very small area of the image that’s sharp. This can be a compelling way of telling a story, particularly if the lens’s design gives a nicely progressive fall off in sharpness. A very fast prime or fixed focal length lenses with a maximum aperture of f1.0 or even f0.95, will reduce the depth of field to a mere sliver when shooting at these settings, giving the potential to create very dramatic visual effects contrasting the sharp with the blurred.
Depth of field is also affected by the focal length of the lens. Wide angle lenses (which have a short focal length, typically in the range of 14mm to 28mm in 35mm format terms) have an inherently greater depth of field at any given f-stop than telephoto lenses (which typically have a focal length of 200mm to 600mm). Depth of field also decreases as the camera to subject distance decreases so with macro photography where sharpness can be very important it’s often a challenge to obtain a wide enough depth of field.
The alternative problem is the risk of underexposure if you’re shooting in lower light conditions and still want to use a small aperture setting to maximise the depth of field. There is, of course, a limit to how much you can slow down the shutter speed as a way of letting more light into the camera to compensate before camera shake becomes an issue and you’ll need to use a tripod. However, with in camera image stabilisation systems becoming more effective some now give up to five stops of correction you may still be able to shoot handheld in some situations.
Alternatively, you can increase the sensitivity or ISO setting as a way of increasing the exposure, but noise may become a problem at settings of ISO 1600 or above. If you want very fine details to still be crisply reproduced, you may still have to resort to using a tripod to eliminate any risk of softening caused by the noise reduction process (or blur caused by camera shake).
Another option is to add more light and one of the benefits of digital capture is that this doesn’t necessary have to be via using electronic flash. Small to mid sized LED type continuous light sources can be used very effectively, especially for macro work, although the challenge is to make your artificial lighting look as natural as possible.
The trick here is to instead focus on a nearer point i.e. in front of your main subject so the depth of field effectively shifts forwards to include more of the foreground, but without losing any sharpness in the background up to infinity.
How do you determine the focusing point which will give you this greatest depth of field and which is, incidentally, the hyperfocal distance? Inevitably, there’s an equation, but applying this in the field isn’t really practical, especially if you’re not so hot at maths. In the ‘olden’ days when lenses all had depth of field scales for a selection of aperture settings marked above the focusing control collar, you simply adjusted the focusing forward until the infinity symbol was positioned over the appropriate f-stop marking in the scale (rather than at the central focusing index mark). Some modern lenses still have depth offield scales, but many zooms, in particular, don’t. Fortunately, there’s a sure fire way you can determine the hyperfocal distance in the field. First find the nearest point in the foreground that you want to be sharp and estimate its distance from the camera… or simply focus on it and check the distance setting on the lens. Doubling this distance will then give you the hyperfocal distance as the rule at play here is that everything from half the hyperfocal distance to infinity will be sharp… at a given focal length and aperture, of course. So, for example, if that nearest point is 2.5 metres from the camera, the hyperfocal distance is five metres and focusing at this distance will give you all the depth of field you need (i.e. from 2.5 metres to at or near infinity). As before, you’ll have more depth of field to play around with in the foreground when using a wider angle lens and/or a smaller aperture setting.
A digital camera provides a back-up, of course, as you can immediately check the image using the magnifying function to determine whether everything you want to be sharp, especially in the foreground, actually is. Alternatively, you could also use this method to help determine the hyperfocal distance. Focus on something at or near the background of your scene and take a shot. Magnify the image in the monitor screen and move the enlarged view slowly from the background to the foreground of the scene while checking the sharpness… the point at which the foreground becomes out of focus is the hyperfocal distance. While the camera will almost certainly perform some sharpening of JPEGs and hence the onscreen image you should still be able to see when details become out of focus. And you can always experiment by taking a few images with the hyperfocal distance moved a little closer and/ or further away.
It’s advisable to use manual focus in these situations, but you can use autofocusing provided it’s set up to allow the precise selection of a particular focusing point and its active area provides sufficient coverage of the scene or subject.
What’s more it’s a control that’s right at your fingertips, ready to be exploited at no extra cost, but with the potential to greatly enhance your photography.
While we’ve never had it better when it comes to cameras that simplify the technicalities of photography (including black and white photography) all those special effects and digital filters, for example but if you really want to be in control of the end result… well, you have to take control. Modern digital cameras retain a full suite of manual controls and, if you’re still flying on auto pilot, you’ll be amazed what you can achieve with them.
It’s really not as difficult as it might look and, once you’re more involved with the picturemaking process, you’ll also be surprised at how much more enjoyable and rewarding your photography will become.
Depth of field is often perceived as the photographic technicality that causes the most confusion and looks the most difficult to comprehend, but once you grasp the basic principle, it’s actually not all that mysterious and certainly very useful in all areas of photography and film photography. Importantly, depth of field may be one of photography’s key technical considerations, but it also has many creative implications.
Starting With F-Stops
Depth of field is the area of an image that’s sharply rendered from the foreground to the background or, more simply, the front to back depth of sharpness. Depth of field is affected by a number of factors which are all lens related, starting with the aperture settings.
The aperture mechanism in a lens (also called the ‘diaphragm’) creates an opening which varies in size, thereby allowing progressively more or less light to pass through and reach the sensor. Along with the shutter speed, the aperture setting is how an exposure is controlled. The size of the aperture is expressed as an ‘f-stop’ which is written as the letter ‘f’ followed by a number. These numbers are determined by a simple equation; the focal length of the lens divided by the diameter of the aperture. You don’t really need to know this because f-stops are always marked on the lens or shown in the camera’s readout displays, but it will help you understand why aperture f-stops are numbered in the opposite way to what would seem logical the larger apertures have smaller f-numbers.
Typically, a modern lens has an aperture range from f2.8 its largest or widest diameter opening to f22, its smallest aperture. However, some lenses, may have a larger maximum aperture say f2.0, even f1.4 and some may have a smaller minimum aperture of f32. Zoom lenses may have a variable maximum aperture which is related to its focal or zooming range such as f3.5-5.6 but some zooms are constant aperture which means there’s no variation in an aperture setting across the zooming range.
Visual Effects
As noted previously, the aperture has an effect on sharpness so you can increase the depth of field by using a smaller setting (for example, f16 or f22) or decrease it by using a larger aperture (say f2.8 or even f1.4). Obviously, this requires manual setting of the aperture, either in the aperture priority auto exposure control mode in which case the camera will automatically set the shutter speed needed to ensure a correct exposure or in the fully manual mode.Controlling the depth of field in this way has visual implications. A shallow depth of field is desirable if you want to throw the background out of focus so it doesn’t create any distractions or conflict with the main subject in your picture. Alternatively, longer depth of field may be required if you want details in both the foreground and background to be in sharp focus such as may be required in landscape photography where both the details in the foreground and background are important.
A very shallow depth of field allows for selective focusing so the viewer’s eye is only drawn to the very small area of the image that’s sharp. This can be a compelling way of telling a story, particularly if the lens’s design gives a nicely progressive fall off in sharpness. A very fast prime or fixed focal length lenses with a maximum aperture of f1.0 or even f0.95, will reduce the depth of field to a mere sliver when shooting at these settings, giving the potential to create very dramatic visual effects contrasting the sharp with the blurred.
Depth of field is also affected by the focal length of the lens. Wide angle lenses (which have a short focal length, typically in the range of 14mm to 28mm in 35mm format terms) have an inherently greater depth of field at any given f-stop than telephoto lenses (which typically have a focal length of 200mm to 600mm). Depth of field also decreases as the camera to subject distance decreases so with macro photography where sharpness can be very important it’s often a challenge to obtain a wide enough depth of field.
Dealing With Exposure
Because changing the aperture also has an effect on exposure, it may not always be possible to just select a larger or smaller setting without making other corrections. In very bright conditions, opening up the aperture may result in overexposure even when using a very fast shutter speed such as 1/4000 or 1/8000 second. In this situation, a neutral density (ND) filter may be needed on the lens to help reduce the amount of light reaching the sensor by another means. These days ND filters are available in a variety of ‘strengths’ some are even adjustable reducing an exposure by as much as ten stops or more.The alternative problem is the risk of underexposure if you’re shooting in lower light conditions and still want to use a small aperture setting to maximise the depth of field. There is, of course, a limit to how much you can slow down the shutter speed as a way of letting more light into the camera to compensate before camera shake becomes an issue and you’ll need to use a tripod. However, with in camera image stabilisation systems becoming more effective some now give up to five stops of correction you may still be able to shoot handheld in some situations.
Alternatively, you can increase the sensitivity or ISO setting as a way of increasing the exposure, but noise may become a problem at settings of ISO 1600 or above. If you want very fine details to still be crisply reproduced, you may still have to resort to using a tripod to eliminate any risk of softening caused by the noise reduction process (or blur caused by camera shake).
Another option is to add more light and one of the benefits of digital capture is that this doesn’t necessary have to be via using electronic flash. Small to mid sized LED type continuous light sources can be used very effectively, especially for macro work, although the challenge is to make your artificial lighting look as natural as possible.
But Wait, There’s More on what is depth of field…
Let’s talk about the hyperfocal distance. Aaargh! The what? Don’t panic, the hyperfocal distance is actually quite an easy concept to grasp and it will help you make the most of the depth of field available with a particular lens focal length and aperture setting. To get the idea, think of the depth of field as a fixed length, say a ruler for example. However, it doesn’t have to stay in a fixed position, you can move it forwards or backwards to alter which parts of the subject or scene are in focus. When you focus on a point, roughly one third of the available depth of field extends in front of that point and the remaining two thirds extends behind it. If you’re focusing at or near infinity the longest distance setting on any lens that two thirds of the depth of field behind the focusing point is effectively wasted while the nearer parts of the foreground will be out of focus.The trick here is to instead focus on a nearer point i.e. in front of your main subject so the depth of field effectively shifts forwards to include more of the foreground, but without losing any sharpness in the background up to infinity.
How do you determine the focusing point which will give you this greatest depth of field and which is, incidentally, the hyperfocal distance? Inevitably, there’s an equation, but applying this in the field isn’t really practical, especially if you’re not so hot at maths. In the ‘olden’ days when lenses all had depth of field scales for a selection of aperture settings marked above the focusing control collar, you simply adjusted the focusing forward until the infinity symbol was positioned over the appropriate f-stop marking in the scale (rather than at the central focusing index mark). Some modern lenses still have depth offield scales, but many zooms, in particular, don’t. Fortunately, there’s a sure fire way you can determine the hyperfocal distance in the field. First find the nearest point in the foreground that you want to be sharp and estimate its distance from the camera… or simply focus on it and check the distance setting on the lens. Doubling this distance will then give you the hyperfocal distance as the rule at play here is that everything from half the hyperfocal distance to infinity will be sharp… at a given focal length and aperture, of course. So, for example, if that nearest point is 2.5 metres from the camera, the hyperfocal distance is five metres and focusing at this distance will give you all the depth of field you need (i.e. from 2.5 metres to at or near infinity). As before, you’ll have more depth of field to play around with in the foreground when using a wider angle lens and/or a smaller aperture setting.
A digital camera provides a back-up, of course, as you can immediately check the image using the magnifying function to determine whether everything you want to be sharp, especially in the foreground, actually is. Alternatively, you could also use this method to help determine the hyperfocal distance. Focus on something at or near the background of your scene and take a shot. Magnify the image in the monitor screen and move the enlarged view slowly from the background to the foreground of the scene while checking the sharpness… the point at which the foreground becomes out of focus is the hyperfocal distance. While the camera will almost certainly perform some sharpening of JPEGs and hence the onscreen image you should still be able to see when details become out of focus. And you can always experiment by taking a few images with the hyperfocal distance moved a little closer and/ or further away.
It’s advisable to use manual focus in these situations, but you can use autofocusing provided it’s set up to allow the precise selection of a particular focusing point and its active area provides sufficient coverage of the scene or subject.
No Cost, Plenty Of Benefit on understanding what is depth of field..
So, depth of field isn’t really scary at all, but a really useful weapon when you need to take charge of what’s in focus in a picture or perhaps more importantly what’s not. As such it’s not only technically important, but has many creative implications. Using the principle of the hyperfocal distance simply extends the scope of what’s possible when maximising the depth of field available at a particular lens focal length and aperture setting.What’s more it’s a control that’s right at your fingertips, ready to be exploited at no extra cost, but with the potential to greatly enhance your photography.
